VDE approved HV temperature sensor for the development of future drive components in the automotive industry

  • Sensor with 4 thermocouples type K, class 1 according to IEC / EN 60584-1
  • PUR insulated thermocouple cable according to IEC / EN 60584-3 in Ø 4,5 mm with wear detection and PI (Polyimid) / Kapton® isolated inner conductor
  • process temperature -50 °C to +200 °C
  • Transient overvoltage up to max. 2.5 kV
  • Tested electric strength 3.6 kV AC
  • Nominal lengths customised from 1m to max. 15 m
  • with Dakks calibration according to DIN EN 17025
  • Testing and repair of sensors already in use

Online request / Configurator

HV-TC sensor 4 x type K, PUR thermocople cable, Ø 4,5 mm
